IronCraft 3515 Flex-Wing Cutter Description
If you have lots of open areas to maintain, don’t waste your time with a small cutter. Spring for IronCraft’s Heavy Duty 15 ft Flex-Wing Cutter. Designed for large tractors with 60 hp or more, the transport width is only 90″ with an optional towing safety light kit, making it easy to tow down the road, a path in the woods, or pass through your fence-gate.
Constructed from 10 ga steel, this heavy duty cutter clears any brush up to 3.5″ in diameter, while deck rings ensure bent blades do not damage the structure of the cutter.
It offers reinforced deck structure from front to rear and side-to-side of the center deck weldment with 1/4″ inch wall tubing along the length of the hinges for extra protection. Wing fold hydraulic cylinder mount spans the entire width of the center deck weldment and ties into the cutter deck lift cylinder to achieve maximum structural integrity.
This cutter is available with 4, 6, or 8 wheels in four tire styles—26″ foam filled, 29″ Aircraft pneumatic, or 20″ laminated, 26″ laminated.
Available for 540 rpm or 1000 rpm PTO shafts.
IronCraft 3515 Flex-Wing Cutter Specs
| Product Family | 3515 Series |
| Product | 3515 |
| Description | 15′ Heavy Duty Flex Wing Rotary Cutter |
| RPM | 540 or 1000 |
| HP Required | 60 minimum PTO |
| Working Width | 180″ |
| Overall Width | 188″ |
| Transport Width | 90″ |
| Tongue Weight | 1900 lb |
| Weight (lbs) | 5600 lbs w/ 6- 26″ laminated tires |
| Cutting Height | 2″ to 15″ |
| Cutting Capacity | 3-1/2″ |
| Deck Thickness | 10 GA |
| Side Bands | 1/4″ x 13-1/2″ |
| Suspension | 2 Heavy Duty Springs Positioned on the center tailwheel axle |
| Skid Shoes | Replaceable |
| PTO Drive Shaft | ASAE CAT 6 |
| Wing Drive PTO | ASAE CAT 4 |
| Driveline Protection | Slip Clutch |
| Blade Holder | Round Pan |
| Gearbox Rating | 235 HP |
| Outboard Gearbox Rating | 190 HP |
| Wing Flex | 22 Degrees Down to 100 Degrees Up |
| Blades | 1/2″ x 4″ Uplift |
| Blade Overlap | 6″ |
| Wheel Type | 20″ or 26″ Laminated, 26″ Foam Filled, or 29″ Pneumatic |
| Hitch Type | Swivel Pivot Self Leveling |
| Gearbox Warranty | 5 year limited |
| Deck Rings | Standard |
| Safety Tow Chain | Standard |
| Guarding Options | Single Row Chains Standard |
| FPM | 17135 |
