Purchase this item and get Description
Compact 4-n-1 Bucket Series HighLights
The cylinders on IronCraft’s compact tractor 4-N-1 Buckets have a 2″ bore. They are equipped with a 1/2″ x 6″ cutting edge and 1/2″ x 4″ at all other ground engaging points.
They are also built with top quality steel, oversized pins and bushings, with grease fittings at every pivot point. Every unit exceeds the lifting capacity of the tractor or skid steer machine it is used on.
- Widths: 60, 66, 72 inches
- Weight: 477 lb, 550 lb, 575 lb
- For Tractors Under 40 Horsepower
- Cutting Edges 1/2″ x 6″
- 2″ Bore Hydraulic Cylinder
- Grease fittings at every pivot point
- Optional weld on teeth
Standard 4-n-1 Bucket Series HighLights
The cylinders on IronCraft’s Standard Duty have a 2.5″ bore. They are equipped with a 1/2″ x 6″ cutting edge and 1/2″ x 4″ at all other ground engaging points.
They are also built with top quality steel, oversized pins and bushings, with grease fittings at every pivot point. Every unit exceeds the lifting capacity of the tractor or skid steer machine it is used on.
- Widths: 60, 66, 72 inches
- Weight: 600 lb, 725 lb, 650 lb
- For Tractors 40–50 Horsepower
- Cutting Edges 1/2″ x 6″
- 2 1/2″ Bore Hydraulic Cylinder
- Grease fittings at every pivot point
- Optional weld on teeth
- Available in JDQA or SSQA
Heavy Duty 4-n-1 Bucket Series HighLights
The cylinders on IronCraft’s Heavy Duty 4-N-1 Buckets have a 2.5″ bore. They are equipped with a 1/2″ x 6″ cutting edge and 1/2″ x 4″ at all other ground engaging points.
They are also built with top quality steel, oversized pins and bushings, with grease fittings at every pivot point. Every unit exceeds the lifting capacity of the tractor or skid steer machine it is used on. Optional weld-on teeth available for Heavy-Duty Buckets.
- Widths: 63, 66, 72 inches
- Weight: 785 lb, 810 lb, 840 lb
- For Tractors 50–65 Horsepower
- Cutting Edges 1/2″ x 6″
- 2 1/2″ Bore Hydraulic Cylinder
- Grease fittings at every pivot point
- Optional weld on teeth
- Available in JDQA or SSQA
X-TREME Duty 4-n-1 Bucket Series HighLights
IronCraft’s X-treme 4-N-1 Buckets have cylinders with a 3″ bore. They are equipped with a 1″ x 8″ cutting edge and 3/4 ” x 6″ at all other ground engaging points.
They are also built with top quality steel, oversized pins and bushings, with grease fittings at every pivot point. Every unit exceeds the lifting capacity of the tractor or skid steer machine it is used on. Optional weld-on teeth available for X-treme Buckets.
- Widths: 72, 78, 81, 84 inches
- Weight: 1150 lb, 1255 lb, 1295 lb, 1271 lb
- For Tractors 65 Horsepower and Above
- Cutting Edges 1″ x 8″
- 3″ Bore Hydraulic Cylinder
- Grease fittings at every pivot point
- Side cutters standard
- Optional weld on teeth and bolt on edge
- Available in JDQA or SSQA
***Hoses and fittings normally not included. If they are included, they may be the wrong length or have the wrong fittings. Consider it a bonus if they are correct. Order at the links below to get what you need to fit your tractor.***
Save 5% with code GWT at Summit Hydraulics!
Buy 3rd function kits for tractors by clicking here.
Buy hydraulic hoses and fittings by clicking here.
