IronCraft Heavy Duty Brush Hog Details
These cutters use a single spindle with two free-swinging blades, which reduce the shock of impact when a stationary object is contacted. A slip clutch protects the gearbox and driveline from damage. Standard equipment includes driveline shields and clutch shields. Front and rear chain and rubber discharge shields are available.
Standard Features
- 7 Gauge Steel Decking
- 3″ Dia Cut Capacity
- Replaceable Skid Shoes
- Slip Clutch Protection
- 540 RPM PTO
- 100 hp Gearbox
- Available Widths: 72″ or 84″
- For Tractors with at least 42 PTO hp
Optional Features
- 1 3/4″ 20 Spline PTO
- 1 3/8″ 21 Splint PTO
- Chain Guard
IronCraft Heavy Duty Brush Hog Specs
| Model | 1606 | 1607 |
| Description | 6′ Heavy Duty Cutter |
7′ Heavy Duty Cutter
|
| RPM | 540 or 1000 | 540 or 1000 |
| HP Required | 47 – 100 PTO |
55 – 100 PTO
|
| Working Width | 72″ | 84″ |
| Weight (lbs) | 1205 lbs | 1375 lbs |
| Cutting Capacity | 3″ | 3″ |
| Deck Thickness | 7 GA | 7 GA |
| Side Bands | 8″ | 8″ |
| PTO Drive Shaft | Series 5 | Series 5 |
| Blade Holder | 1/2″ | 5/8″ |
| Gearbox Rating | 100 HP | 100 HP |
| Wheel Type | Laminated | Laminated |
| Hub Type | Greaseable | Greaseable |
| Hitch | Cat 1 & 2 | Cat 1 & 2 |
| Guarding Options | Rubber Guards or Chains |
Rubber Guards or Chains
|
